Nano Programmable Logic Controller (02)

Product Description:

Specification of Nano Programmable Logic Controller – 02

Counter – 1 Total Count.
a) Counter Range – 999999 Count Max.
b) Counter Pulse – Internally from sequence software command.
No. of Timers - 16 max.
a) Timers Range – 00.00 to 99.99 Sec.
b) Timers Least Count – 10 Millisecond
c) Timers Accuracy - ± .01%
d) Time Base – Quartz Crystal
e) Counting Mode of Timers – Down counting Type Std. Up counting on Request.

No. of Inputs - 02
a) Input Voltage – 24 VDC Std.
b) Must on Voltage – 14VDC
c) Min. Input pulse width – 20msec.
No. of Outputs – 02
a) Output Voltage – 24VDC Std.
b) Output Type – Transistor Open collector O/P OR Relay Output.
c) Output Current – 1Amp-Max.
Sequence of Operation – As per customer provided sequence of operation.
Front
a) Display – 2 line Alphanumeric character LCD Display to display All settings & operational
parameters.
b) Keys – 8 Keys Keyboard below LCD Display to enter all settable parameters &
give Auto/MAN commands etc.
Back 2, 8 way terminals for Inputs, Outputs & power to PLC.
Power
a) Power to unit ± 24VDC/500Ma
±10%
OR
230 V AC ± 10%, Single phase 50 Hz.
b) Power for I/O operation
± 24 VDC
Size
a) Cutout – 90 x 90 mm
b) Overall – 96 x 96 x 120mm.
